Lower Lateral System
PVC lower lateral hub system with six laterals for 6” flanged Eurotrol pressure vessels. Includes AISI 304 bolts and washers. Available in 0.2 mm or 0.5 mm slots.
Description
The Lower Lateral System is designed for 6” flanged pressure vessels, providing efficient water distribution and reliable filtration performance. Each system features a flanged hub with six laterals for even flow distribution within the vessel. Manufactured from durable PVC and complete with AISI 304 stainless steel bolts and washers, this unit ensures long-term mechanical integrity and chemical resistance.
Available in configurations with slot sizes of 0.2 mm or 0.5 mm, the lower lateral system is suitable for vessels ranging from 18” to 36” in diameter. It provides optimal flow and pressure loss characteristics, making it ideal for both industrial and commercial filtration systems.
Key Features
-
Lower lateral system for 6” flanged pressure vessels
-
Flange material: PVC
-
Includes AISI 304 bolts and washers
-
Hub with 6 laterals
-
Lateral options in PP with slot openings of 0.2 mm or 0.5 mm
-
Lengths designed according to vessel size (18” – 36”)
Typical Applications
Used in water treatment and filtration systems where uniform flow distribution and mechanical strength are required — including industrial, process, and municipal installations.
Technical specifications
| Connection | DN 65 |
|---|---|
| Lateral Hub | 6-way flanged type |
| Slot Size | 0.2 mm or 0.5 mm |
| Material | PVC with PP laterals |
| Bolts and Washers | AISI 304 stainless steel |
| Vessel Diameters | 18”, 24”, 30”, 36” |
| Operating Flow (Δ0.2 mm) | 22 – 25 m³/h |
| Operating Flow (Δ0.5 mm) | 22 – 25 m³/h |
| Operating Pressure | Up to 6 bar |
